No. 169. Armchair bed made of plywood.

0 ratings
Add to cart

No. 169. Armchair bed made of plywood.

$5
AWBox
0 ratings

Drawings for the manufacture of chair beds from plywood. Material - plywood 21 and 18mm.


Dimensions:

in position "chair"

height on the back - 1147mm

seat height - 460mm

length - 849mm

width -860mm


in the "bed" position

height on a pillow - 350mm

body height - 250mm

length - 2146mm

width -860mm


In the archive:

- visualizations

- drawings of parts in pdf

- complete drawings

- xlsx file with drilldown. with the ability to automatically recalculate to the desired seat width.

Level: Intermediate

Required tool: grinder, clamps, saw, milling cutter (optional).

Consumables: dowels 8 * 30mm, screws, nuts, wood glue, sandpaper

Text in Russian

A set of drawings is presented as is. Designed for users with experience. Claims related to the drawings, the manufacturing process are not accepted.
